Turbo turbocharger model: HT3B turbocharger;
Assy3009426; Cust3018654;
Booster assembly number Assy: 3529040;
Booster customer number Cust: 3529041;
Booster OEM: 3529045;
Matching engine: suitable for Cummins NT855/C400 water-cooled explosion-proof engine;
BHT3B Turbo 3529040
Product Descriptio Booster Technical Parameters Introduction
| Part NumberSupercharger assembly number | 3529040 |
| Previous Version Supercharger Customer Number | 4033543, 3003709, 3009426, 3011731, 3011733, 3018654, 3019414, 3024387, 3026924, 3032051, 3032052, 3032057, 3032058, 30320 60, 3032061, 3032062, 3032063, 3032066, 3032068, 3036165, 3036309, 3527693, AR09476, AR12630, AR12632, AR51541, AR51954, 144700-0000 |
| OE number supercharger general number | 3801939, 3801968, 3801967, 3801936, 3801938, 3801939, 3801990 |
| YearSupercharger manufacturing time | 2021/10/3 |
| DescriptionEngine type | Cummins (CTT) Genset, Samsung FR20, SD20, Chongqing Mixer, Various |
| Manufacturer Part Number | 150063, 150064, 4049140 |
| CHRA supercharger manufacturer nationality | 167212 (4027924), MADE IN CHINA |
| Turbo ModelSupercharger model | HT3B, ST50, T46, VT50, BHT3B |
| Engine model | NTA855-P |
| DisplacementEngine displacement | 14.0L, 21400 cc |
| Fuel | Diesel |
| Engine ManufacturerEngine Manufacturer | Cummins |
| Bearing Housing | 3522740 (352274000)(196117) |
| Turbine Wheel supercharger turbine shaft part numbers and dimensions | 3594952 (3522075, 196370, 144410-0000)(Ind. 97. mm, Exd. 86.4 mm, 12 Blades) (1152304435) |
| Comp. Wheel Supercharger Compressor Impeller Part Number and Dimensions | 3527047 (Ind. 73.5 mm, Exd. 109. mm, 8+8 Blades)(1152304401) |
| Back plate | 59618 (3500710, 3759618, 166084, 183472, 143144-0000) (1150704300) |
| Heat shield Number | 3519155 (3758538, 375853800) |
| Repair Kit Supercharger repair kit part number | 3545669 (3575230)(1152304750, 1153060752) |
suit：Cummins Various with NTA855-P Engine
